plate and tube parameters |
|
|
clamping mode |
Feeding chuck pneumatic, front chuck manual |
|
cutting length |
6000mm |
|
chuck |
Changzhou Jingka |
|
Cutting minimum diameter |
10mm |
|
Maximum cutting diameter |
Round tube 160mm, square tube 100mm |
|
Drive mode |
Front and rear double drive |
|
Drive motor |
Front card |
|
plate tube servo |
Front chuck 2KW, rear chuck 3KW, transmission servo 2KW |
|
Total installed power consumption |
<15KW |
|
electricity demand |
380V/50Hz |
|
chuck parameter |
Aperture 220 chuck
|
